Acute Punch

Name: Acute Punch
Brand: FABMAX
Price: 150.00 $
Availability: InStock
Rating: 5 (1 reviews)

ADD TO CART

TEAMS

Dedicated service teams.

KNOW-HOW

More than 25 years of experience

QUALITY

Outstanding quality

SERVICE

24-hour quick response

Information
FABMAX-System Amada

Angle： 60°
Radius：R 6 mm
Height：65 mm
Load：1000 kN/m max.
Material：42CrMo, 650 - 800 N/mm

Punch FEature

1. Most tools can be easily loaded by a single operator.
2. Easy to store.
3. All sectionalised tools come pre-cut in nine different pieces.
4. Most sectionalised punches include two ear pieces (horns).
5. Punches are induction hardened, to 45-50 HRC but 55-60HRC is available for every punch in the tooling line.
6. Special Tooling available.

PUNCH SECTION LENGTHS: 100mm LEFT EAR / 100mm RIGHT EAR / 10mm / 15mm / 20mm / 40mm / 50mm / 200mm / 300mm Note: Special lengths are available at additional cost, just select the standard length and ask us to cut to your requirements.

Air Bending Force
Air bending force

Required press force at 90° air bending, force in ton/mtr.

The charts below give the appropriate tonnage to air bend mild steel.

Bending force for other metals:

Soft aluminium Tons per unit length x 50%

Aluminium alloys heat treated Tons per unit length x 100%

Stainless Tons per unit length x 150%

Items
Order：

Minimum order is $20.00.

Special Orders：

All special orders are non-cancelable, non-returnable, and non-refundable.

Payment Terms：

Terms are net 10 days. Catalog prices are subject to change without notice.

Freight：

Orders are shipped F.O.B. from our manufacturing facility. (International Shipments are Incoterms: Ex Works).

Order Cancellation：

In the event an order is cancelled, an additional charge will be assessed to cover the cost of labor and material.

Returned Material：

A handling/restocking fee will be applied to all products returned for credit. A return authorization number and shipping instructions must be obtained in advance before an item can be returned.

Claims：

All claims or product shortages must be made within 30 days of the invoice date.

Description
Find your acute punch in Fabmax company:

Acute Punch crafted with meticulous attention to detail, this acute punch is essential for achieving accurate bends and exceptional finishes in various metal forming applications.

This press brake punch is ideally suited for industries requiring precise shaping and bending of metal sheets, including automotive, aerospace, manufacturing, and fabrication. Its versatile design allows for a wide range of bending angles and complex profiles, making it an invaluable addition to your tooling inventory.

Whether you're involved in high-volume production or custom metalwork, this tool will enhance your operational efficiency and output quality.

With us, explore the benefits of our expertly designed tools today and experience a new standard in metal fabrication.

Welcome to visit Fabmax!

Product Features and Description

Precision Bending and Customization

This acute punch is designed for high-precision bending with customizable options to meet your specific production requirements. It ensures accurate results for complex parts and critical tolerances.

Hydraulic Clamping System Compatibility

Works flawlessly with hydraulic clamping systems, providing superior grip and stability during the bending process. This feature enhances the speed and efficiency of your press brake operations, reducing downtime and increasing productivity.

Durable Construction for Long-Term Performance

Made from high-quality materials, this acute punch is built to withstand heavy-duty applications, ensuring a long lifespan and reducing maintenance needs. It maintains its performance even under demanding workloads.

Versatile and Customizable Tooling

This acute punch is part of a wide range of custom press brake tooling options that can be tailored to fit various press brake machines. It's an excellent choice for industries such as automotive, aerospace, and metal fabrication.

Product Advantages
- Enhanced Precision: Provides accurate and repeatable bends with tight tolerances, ideal for high-precision applications.
- Improved Efficiency: Works seamlessly with hydraulic clamping systems, reducing setup time and improving workflow.
- Durability: Built to last with high-strength materials, ensuring long-term reliability and reduced tool replacement costs.
- Customizable Solutions: Tailored options for unique production needs, offering flexibility in press brake operations.

Soft aluminium	Tons per unit length x 50%
Aluminium alloys heat treated	Tons per unit length x 100%
Stainless	Tons per unit length x 150%

Acute Punch

FABMAX-System Amada

Angle： 60° Radius：R 6 mm Height：65 mm Load：1000 kN/m max. Material：42CrMo, 650 - 800 N/mm
