Shearing blade

Name: Shearing blade
Brand: FABMAX
Availability: InStock
Rating: 5 (1 reviews)

$0.00Excl.tax Excl. Shipping costs

ADD TO CART

TEAMS

Dedicated service teams.

KNOW-HOW

More than 25 years of experience

QUALITY

Outstanding quality

SERVICE

24-hour quick response

Information

Fabmax has been producing shear blades for more than 20 years, using high quality steel to guarantee reliability and wealresistance.
Each product is studied on customer's needs: material to cut, holes and hardening upon your requestBlades with 1.2 or 4 cutting edges with threaded holes or dimpled holes.

Available sizes mm (in)
50(1.97)	50(2.17)	60(2.36)	65(2.56)	70(2.76)	75(2.95)	80(3.15)	85(3.35)	90(3.54)	100(3.94)
50x10(1.97x 039)
50x11(1.97x0.43)
50x12(1.97x0.47)	55x12(2.17x0.47)	60x12(2.36x0.51)
50x13(1.97x0.51)	55x13(2.17x0.51)	60x13(2.36x0.51)	65x13(2.56x0.51)	70x13(2.76x0.51)
50x14(1.97x0.55)	55x14(2.17x0.55)	60x14(2.36x0.55)	65x14(2.56x0.55)	70x14(2.76x0.55)
50x15(1.97x0.59)	55x15(2.17x0.59)	60x15(2.36x0.59)	65x15(2.56x0.59)	70x15(2.76x0.59)	75x15(2.95x0.59)
	55x16(2.17x0.63)	60x16(2.36x0.63)	65x16(2.56x0.63)	70x16(2.76x0.63)	75x16(2.95x0.63)
	55x17(2.17x0.67)	60x17(2.36x0.67)	65x17(2.56x0.67)	70x17(2.76x0.67)	75x17(2.95x0.67)
	55x18(2.17x0.71)	60x18(2.36x0.71)	65x18(2.56x0.71)	70x18(2.76x0.71)	75x18(2.95x0.71)	80x18(3.15x0.71)	85x18(3.35x0.71)
	55x19(2.17x0.75)	60x19(2.36x0.75)	65x19(2.56x0.75)	70x19(2.76x0.75)	75x19(2.95x0.75)	80x19(3.15x0.75)	85x19(3.35x0.75)
	55x20(2.17x0.79)	60x20(2.36x0.79)	65x20(2.56x0.79)	70x20(2.76x0.79)	75x20(2.95x0.79)	80x20(3.15x0.79)	85x20(3.35x0.79)	90x20(3.54x0.79)	100x20(3.94x0.79)
					75x21(2.95x0.83)	80x21(3.15x0.83)	85x21(3.35x0.83)	90x21(3.54x0.83)
					75x22(2.95x0.87)	80x22(3.15x0.87)	85x22(3.35x0.87)	90x22(3.54x0.87)
					75x23(2.95x0.91)	80x23(3.15x0.91)	85x23(3.35x0.91)	90x23(3.54x0.91)
					75x24(2.95x0.94}	80x24(3.15x0.94)	85x24(3.35x0.94)	90x24(3.54x0.94)
					75x25(2.95x0.98)	80x25(3.15x0.98)	85x25(3.35x0.98)	90x25(3.54x0.98)	100x25(3.94x0.98)
									100x26(3.94x1.02)
									100x27(3.94x1.06)
									100x28(3.94x1.10)
									100x29(3.94x1.14)
									100x30(3.94x1.18)

Standard tolerances
Hardeness	Height	Width	Parallelism
±1HRC	±0.5mm	±0.2mm	±0.03mm

Items
Order：

Minimum order is $20.00.

Special Orders：

All special orders are non-cancelable, non-returnable, and non-refundable.

Payment Terms：

Terms are net 10 days. Catalog prices are subject to change without notice.

Freight：

Orders are shipped F.O.B. from our manufacturing facility. (International Shipments are Incoterms: Ex Works).

Order Cancellation：

In the event an order is cancelled, an additional charge will be assessed to cover the cost of labor and material.

Returned Material：

A handling/restocking fee will be applied to all products returned for credit. A return authorization number and shipping instructions must be obtained in advance before an item can be returned.

Claims：

All claims or product shortages must be made within 30 days of the invoice date.

Description
Reducing Friction and Adhesion

For demanding applications, our shearing blades can be treated with advanced surface coatings (e.g., TiN, TiCN, or proprietary polymer coatings). These coatings significantly reduce the coefficient of friction and prevent material adhesion or "sticking," which is common when shearing soft metals like aluminum or brass. Reduced friction means lower cutting forces, less heat generation, and cleaner edges, ultimately extending the interval between sharpening cycles and preserving the integrity of the shear knife surface.

Optimizing Cutting Speed

High-speed shearing operations can lead to significant heat generation at the cutting edge, which can compromise the blade's temper and hardness. Our specialized shearing blade materials and designs are chosen to dissipate heat efficiently. Operators should also optimize cutting speed and ensure proper lubrication (where applicable) to minimize thermal stress. By controlling thermal build-up, we prevent rapid dulling and ensure the edge integrity of the shear knife is maintained for prolonged periods of continuous, heavy-duty use.
